Tungsten Carbide Tile Sliding Radial Bearing Sleeve Type Customizable Size

Tungsten Carbide Tile Sliding Radial Bearing Sleeve Type Customizable Size

  • Tungsten Carbide Tile Sliding Radial Bearing Sleeve Type Customizable Size
  • Tungsten Carbide Tile Sliding Radial Bearing Sleeve Type Customizable Size
  • Tungsten Carbide Tile Sliding Radial Bearing Sleeve Type Customizable Size
  • Tungsten Carbide Tile Sliding Radial Bearing Sleeve Type Customizable Size
Tungsten Carbide Tile Sliding Radial Bearing Sleeve Type Customizable Size
Product Details:
Place of Origin: CHINA
Brand Name: ASEEDER
Certification: IS0,IPA
Model Number: ASEEDER-042
Payment & Shipping Terms:
Minimum Order Quantity: 20 pieces
Price: Negotation
Packaging Details: foam + small box + carton
Delivery Time: 12-20 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 15 tons per months
Contact Now
Detailed Product Description
Materials: Tungsten Carbide Size: Customizable
Type: Sleeve Samples: Free
Delivery: 15-20days Price: Negotation
High Light:

sliding radial bearing

,

mud motor radial bearing

High Hardness OEM ODM Customized Tungsten Carbide Tile Sliding Radial Bearing Sleeve



1. Abrasive resistant,corrosion free,good compression property, high wear-resistant bushing ,heat resistance,low maintenance;

2. The hardness is 10 times of gold,5 times of tool steel,4 times of titanium , oil resistance,separate the harmful medium;



Tungsten Carbide Tile Sliding Radial Bearing Sleeve Type Customizable Size 0

Our advantages:

1. Use 100% Raw material, strict incoming inspection.

2. Overpressure sintering, increasing the densification of the alloy teeth and increasing the 30% life span.

3. Can be customized according to the requirements of the customer.



Materials grade:

Grade

ASEEDER

Specification Application of tungsten carbide
Density TRS Hardness
G/Cm3 N/mm2 HRA
ZY06X 14.8-15.1 ≥1560 ≥91.0 Qualified for machining of chilled cast iron, alloy cast iron, refractory steel and alloy steel. Also Qualified for the machining of common cast iron.
ZY06 14.7-15. 1 ≥1670 ≥89.5 Qualified for finish machining and semi-finish machining for the cast iron, non-ferrous metal, alloy and unalloyed materials. Also qualified for wire drawing for the steel and non-ferrous metal, electric drill for geology use and steel drill etc.
ZY08 14.6-14.9 ≥1840 ≥89 Qualified for rough machining of cast iron, non-ferrous metal, non-metal materials, drawing of steel, non-ferrous metal and pipes, various drills for geology use, tools for machine manufacture and wearing parts.
ZY09 14.5-14.8 ≥2300 ≥91.5 Qualified for low speed rough machining, milling titanium alloy and refractory alloy, especially for cut-off tool and silk prick.
ZY11C 14-.3-14.6 ≥2100 ≥86.5 Qualified for molding the drills for heavy-duty rock drill: detachable bits used for deep hole drilling, rock drill trolley etc.
ZY15 13.9-14.1 ≥2020 ≥86.5 Qualified for hard rock drilling, steel bars with high compression ratios, pipe drawing, punching tools, core cabinet of powder metallurgy automatic molders etc.
ZY20 13.4-14.8 ≥2480 ≥83.5 Qualified for making dies with low impact such as punching watch parts, battery shells, small screw caps etc.
ZY25 13.4-14.8 ≥2480 ≥82.5 Qualified for making mould of cold heading, cold stamping and cold pressing used for manufacturing standard parts, bearings etc.



Tungsten Carbide Tile Sliding Radial Bearing Sleeve Type Customizable Size 1



Factory information:



Seed Technologies Corp., LTD., located in Zhuzhou (China), is a high-tech developer, manufacturer, and distributor of superior wear resistant parts, tool assembly and equipment for Oil and gas, Areospace, Valve and Pumps industry..
Aseeder Corporation was invested by Seed as a Houston based company dedicated for sales and customer support in north America market.



Major Product Lines

· Wear resistant carbide components via powder metallurgy technique

· Hardfacing (oxy-acetylene spray, PTA, HVOF, etc.) and surface enhancement (phosphating, boronizing, etc.)

· High-precision machining of metals (S.Steel, carbon steel, Inconel 718, etc.)

· Additive manufacture

Tungsten Carbide Tile Sliding Radial Bearing Sleeve Type Customizable Size 2

The products and technologies from Seed (Aseeder) have been widely applied in the fields of oil & gas, chemical engineering, subsea, nuclear power and aerospace industries. Mainly used in harsh operating conditions include severe abrasion, erosion, corrosion, high temperature, high pressure and strong impact. Our major clients are Fortune 500 companies. Seed is the leading export enterprise in China of wear-resistant cemented carbide products and the related high-precision machining techniques.



Representative Products

Chokes and valves trim parts
Pumps seal rings
Labyrinth product series
Drill bit nozzles, inserts, cutters
MWD parts, downhole tool components
TC bearings, PDC thrust bearings
Downhole flow control components
Artificial lift pumps components
Super hard product series
Innovative hardfacing solutions
